A Coding Implementation of End-to-End Brain Decoding from MEG Signals Using NeuralSet and Deep Learning for Predicting Linguistic Features Meta Introduces Autodata: An Agentic Framework That Turns AI Models into Autonomous Data Scientists for High-Quality Training Data Creation A Coding Guide on LLM Post Training with TRL from Supervised Fine Tuning to DPO and GRPO Reasoning Qwen AI Releases Qwen-Scope: An Open-Source Sparse AutoEncoders (SAE) Suite That Turns LLM Internal Features into Practical Development Tools A Coding Deep Dive into Agentic UI, Generative UI, State Synchronization, and Interrupt-Driven Approval Flows Moonshot AI Open-Sources FlashKDA: CUTLASS Kernels for Kimi Delta Attention with Variable-Length Batching and H20 Benchmarks Microsoft Research’s World-R1 Uses Flow-GRPO and 3D-Aware Rewards to Inject Geometric Consistency Into Wan 2.1 Without Architectural Changes A Coding Implementation on Pyright Type Checking Covering Generics, Protocols, Strict Mode, Type Narrowing, and Modern Python Typing IBM Releases Two Granite Speech 4.1 2B Models: Autoregressive ASR with Translation and Non-Autoregressive Editing for Fast Inference Top 10 KV Cache Compression Techniques for LLM Inference: Reducing Memory Overhead Across Eviction, Quantization, and Low-Rank Methods Qwen Team Releases FlashQLA: a High-Performance Linear Attention Kernel Library That Achieves Up to 3× Speedup on NVIDIA Hopper GPUs Step by Step Guide to Build a Complete PII Detection and Redaction Pipeline with OpenAI Privacy Filter Meta FAIR Releases NeuralSet: A Python Package for Neuro-AI That Supports fMRI, M/EEG, Spikes, and HuggingFace Embeddings smol-audio: A Colab-Friendly Notebook Collection for Fine-Tuning Whisper, Parakeet, Voxtral, Granite Speech, and Audio Flamingo 3 A Coding Implementation on Document Parsing Benchmarking with LlamaIndex ParseBench Using Python, Hugging Face, and Evaluation Metrics Poolside AI Introduces Laguna XS.2 and M.1: Agentic Coding Models Reaching 68.2% and 72.5% on SWE-bench Verified OpenAI Releases Privacy Filter: A 1.5B-Parameter Open-Source PII Redaction Model with 50M Active Parameters Top 10 Physical AI Models Powering Real-World Robots in 2026 How to Build a Lightweight Vision-Language-Action-Inspired Embodied Agent with Latent World Modeling and Model Predictive Control Meet Talkie-1930: A 13B Open-Weight LLM Trained on Pre-1931 English Text for Historical Reasoning and Generalization Research Build a Reinforcement Learning Powered Agent that Learns to Retrieve Relevant Long-Term Memories for Accurate LLM Question Answering OpenMOSS Releases MOSS-Audio: An Open-Source Foundation Model for Speech, Sound, Music, and Time-Aware Audio Reasoning Meta AI Releases Sapiens2: A High-Resolution Human-Centric Vision Model for Pose, Segmentation, Normals, Pointmap, and Albedo The LoRA Assumption That Breaks in Production How to Build a Fully Searchable AI Knowledge Base with OpenKB, OpenRouter, and Llama How to Build Smarter Multilingual Text Wrapping with BudouX Through Parsing, HTML Rendering, Model Introspection, and Toy Training Top 7 Benchmarks That Actually Matter for Agentic Reasoning in Large Language Models RAG Without Vectors: How PageIndex Retrieves by Reasoning A Coding Tutorial on Datashader on Rendering Massive Datasets with High-Performance Python Visual Analytics xAI Launches grok-voice-think-fast-1.0: Topping τ-voice Bench at 67.3%, Outperforming Gemini, GPT Realtime, and More
How to Build Traceable and Evaluated LLM Workflows Using ...
Sana Hassan · 2026-04-29 · via MarkTechPost

In this tutorial, we build a complete, production-style LLM workflow using Promptflow within a Colab environment. We begin by setting up a reliable keyring backend to avoid OS dependency issues and securely configure our OpenAI connection. From there, we establish a clean workspace and define a structured Prompty file that acts as the core LLM component of our pipeline. We then design a class-based flex flow that combines deterministic preprocessing with LLM reasoning, allowing us to inject computed hints into model responses. We also enable tracing to monitor each execution step, run both single- and batch-queries, and generate outputs in a structured format. Finally, we extend the system with an evaluation pipeline that leverages an LLM-as-a-judge to score responses against expected answers.

!pip install -q keyrings.alt


import keyring
from keyrings.alt.file import PlaintextKeyring
keyring.set_keyring(PlaintextKeyring())


import os
from promptflow.client import PFClient
from promptflow.connections import OpenAIConnection


pf = PFClient()
CONN = "open_ai_connection"
try:
   pf.connections.get(name=CONN)
   print(f"Using existing connection '{CONN}'")
except Exception:
   pf.connections.create_or_update(
       OpenAIConnection(name=CONN, api_key=os.environ["OPENAI_API_KEY"])
   )
   print(f"Created connection '{CONN}'")

We begin by installing a fallback keyring backend to avoid dependency issues in environments like Colab. We then initialize the Promptflow client and check if an OpenAI connection already exists. If not, we create one using the API key from the environment, ensuring a reusable and consistent connection setup.

!pip install -q "promptflow>=1.13.0" "promptflow-tracing" "promptflow-tools" openai


import os, sys, json, getpass, textwrap, importlib
from pathlib import Path


if "OPENAI_API_KEY" not in os.environ:
   os.environ["OPENAI_API_KEY"] = getpass.getpass("Paste your OpenAI API key: ")


WORK_DIR = Path("/content/pf_demo"); WORK_DIR.mkdir(exist_ok=True, parents=True)
os.chdir(WORK_DIR); sys.path.insert(0, str(WORK_DIR))


from promptflow.client import PFClient
from promptflow.connections import OpenAIConnection
from promptflow.tracing import start_trace


pf = PFClient()
CONN = "open_ai_connection"
try:
   pf.connections.get(name=CONN); print(f"Using existing connection '{CONN}'")
except Exception:
   pf.connections.create_or_update(OpenAIConnection(name=CONN, api_key=os.environ["OPENAI_API_KEY"]))
   print(f"Created connection '{CONN}'")

We install all required Promptflow libraries and set up the project’s working directory. We securely capture the OpenAI API key if it is not already set and configure the environment accordingly. We then reinitialize the Promptflow client and ensure that the connection is properly established for downstream usage.

(WORK_DIR / "researcher.prompty").write_text("""---
name: Researcher
description: Concise research assistant.
model:
 api: chat
 configuration:
   type: openai
   connection: open_ai_connection
   model: gpt-4o-mini
 parameters:
   temperature: 0.2
   max_tokens: 350
inputs:
 question: {type: string}
 hint:     {type: string, default: ""}
sample:
 question: "What is the speed of light in vacuum?"
 hint: ""
---
system:
You are a precise research assistant. Answer in 1-3 sentences. If a `hint` is given, weave it in.


user:
Q: {{question}}
{% if hint %}Hint: {{hint}}{% endif %}
""")


(WORK_DIR / "flow.py").write_text(textwrap.dedent('''
   from pathlib import Path
   from promptflow.tracing import trace
   from promptflow.core import Prompty


   BASE = Path(__file__).parent


   @trace
   def safe_calc(expression: str) -> str:
       """A tiny deterministic 'tool' the assistant can lean on."""
       if not set(expression) <= set("0123456789+-*/(). "):
           return "unsafe"
       try: return str(eval(expression))
       except Exception as e: return f"error:{e}"


   class ResearchAssistant:
       """Class-based flex flow. __init__ args become flow init parameters."""
       def __init__(self, model: str = "gpt-4o-mini"):
           self.model = model
           self.llm = Prompty.load(source=BASE / "researcher.prompty")


       @trace
       def __call__(self, question: str) -> dict:
           hint = ""
           if "*" in question or "+" in question:
               tokens = [t for t in question.replace("?","").split() if any(c.isdigit() for c in t)]
               expr = "".join(tokens)
               if expr:
                   hint = f"computed: {expr} = {safe_calc(expr)}"


           answer = self.llm(question=question, hint=hint)


           return {"question": question, "answer": str(answer).strip(), "hint_used": hint}
'''))


(WORK_DIR / "flow.flex.yaml").write_text(
   "$schema: https://azuremlschemas.azureedge.net/promptflow/latest/Flow.schema.json\n"
   "entry: flow:ResearchAssistant\n"
)

We define a Prompty file that structures how the LLM should behave as a concise research assistant. We then create a class-based flow that combines a deterministic calculation tool with an LLM call, enabling hybrid reasoning. Finally, we register this flow using a YAML configuration, making it executable within the Promptflow framework.

try: start_trace()
except Exception as e: print("trace ui unavailable on Colab — traces still recorded:", e)


import flow as _flow; importlib.reload(_flow)
agent = _flow.ResearchAssistant(model="gpt-4o-mini")


print("\n=== Single call ===")
print(json.dumps(agent(question="In one sentence, what is photosynthesis?"), indent=2))
print(json.dumps(agent(question="What is 21 * 19 ?"), indent=2))


data = [
   {"question": "What is the capital of France?",          "expected": "Paris"},
   {"question": "Chemical symbol for gold?",               "expected": "Au"},
   {"question": "Who wrote the play Hamlet?",              "expected": "Shakespeare"},
   {"question": "What is 12 * 11 ?",                       "expected": "132"},
   {"question": "Boiling point of water at sea level (C)?","expected": "100"},
   {"question": "Largest planet in our solar system?",     "expected": "Jupiter"},
]
data_path = WORK_DIR / "data.jsonl"
data_path.write_text("\n".join(json.dumps(r) for r in data))


print("\n=== Batch run ===")
base_run = pf.run(
   flow=str(WORK_DIR / "flow.flex.yaml"),
   data=str(data_path),
   column_mapping={"question": "${data.question}"},
   stream=True,
)
print(pf.get_details(base_run))

We enable tracing to capture execution details and instantiate our research assistant flow. We test the system with individual queries to verify both natural language and arithmetic handling. We then prepare a dataset and run a batch job in Promptflow, collecting structured outputs for further evaluation.

(WORK_DIR / "judge.prompty").write_text("""---
name: Judge
model:
 api: chat
 configuration:
   type: openai
   connection: open_ai_connection
   model: gpt-4o-mini
 parameters:
   temperature: 0
   max_tokens: 150
   response_format: {type: json_object}
inputs:
 question: {type: string}
 answer:   {type: string}
 expected: {type: string}
---
system:
You are an exacting grader. Decide whether the assistant's answer contains the expected fact (case-insensitive, allowing reasonable phrasing/synonyms). Reply ONLY as JSON: {"score": 0 or 1, "reason": "..."}.


user:
Question: {{question}}
Expected: {{expected}}
Answer:   {{answer}}
""")


(WORK_DIR / "eval_flow.py").write_text(textwrap.dedent('''
   import json
   from pathlib import Path
   from promptflow.tracing import trace
   from promptflow.core import Prompty


   BASE = Path(__file__).parent


   class Evaluator:
       def __init__(self):
           self.judge = Prompty.load(source=BASE / "judge.prompty")


       @trace
       def __call__(self, question: str, answer: str, expected: str) -> dict:
           raw = self.judge(question=question, answer=answer, expected=expected)
           if isinstance(raw, str):
               try: raw = json.loads(raw)
               except Exception: raw = {"score": 0, "reason": f"unparseable:{raw[:80]}"}
           return {"score": int(raw.get("score", 0)), "reason": str(raw.get("reason",""))}


       def __aggregate__(self, line_results):
           """Run-level aggregation. Whatever this returns shows up in pf.get_metrics()."""
           scores = [r["score"] for r in line_results if r]
           return {
               "accuracy": (sum(scores) / len(scores)) if scores else 0.0,
               "passed":   sum(scores),
               "total":    len(scores),
           }
'''))


(WORK_DIR / "eval.flex.yaml").write_text(
   "$schema: https://azuremlschemas.azureedge.net/promptflow/latest/Flow.schema.json\n"
   "entry: eval_flow:Evaluator\n"
)


print("\n=== Evaluation run ===")
eval_run = pf.run(
   flow=str(WORK_DIR / "eval.flex.yaml"),
   data=str(data_path),
   run=base_run,
   column_mapping={
       "question": "${data.question}",
       "expected": "${data.expected}",
       "answer":   "${run.outputs.answer}",
   },
   stream=True,
)


eval_details = pf.get_details(eval_run)
print(eval_details)


print("\n=== Aggregated metrics (from __aggregate__) ===")
print(json.dumps(pf.get_metrics(eval_run), indent=2))


import pandas as pd
if "outputs.score" in eval_details.columns:
   s = pd.to_numeric(eval_details["outputs.score"], errors="coerce").fillna(0)
   print(f"Manual accuracy: {s.mean():.2%}  ({int(s.sum())}/{len(s)})")

We create a judging Prompty that evaluates model outputs against expected answers using structured JSON responses. We implement an evaluator class that parses results, computes scores, and defines an aggregation method for overall metrics. Also, we run the evaluation pipeline, link it to the base run, and compute accuracy both through Promptflow metrics and a manual fallback.

In conclusion, we built a robust, modular LLM pipeline that extends beyond basic prompt-response interactions. We integrated deterministic tools, structured prompting, and reusable flow components to create a system that is both transparent and scalable. Through batch execution and linked evaluation runs, we established a clear feedback loop that helps us measure performance using accuracy metrics and detailed reasoning. The inclusion of tracing and aggregation functions enables us to debug, monitor, and improve the system efficiently. Also, this workflow demonstrates how we can design reliable, end-to-end LLM applications with strong foundations in structure, evaluation, and reproducibility.
